Views: 0 Author: Site Editor Publish Time: 2025-09-25 Origin: Site
With digital work and entertainment becoming mainstream, any unexpected power outage or voltage fluctuation can lead to the loss of important data or even damage to the computer hardware. An uninterruptible power supply (UPS) is a key device to mitigate this risk. The newly launched GD-UP09/10/11/12 Smart UPS series, with its compact and intelligent design, provides PC users with instant and reliable power backup.
This series utilizes microprocessor control technology to ensure high system reliability. The built-in Automatic Voltage Regulation (AVR) function monitors voltage fluctuations in real time and intelligently stabilizes output, effectively protecting connected sensitive electronic devices. Its unique DC start function allows for normal startup even without mains power, providing greater flexibility in emergency power needs.
The GD-UP09/10/11/12 series supports automatic restart upon mains power restoration and features an overload protection mechanism, further enhancing operational safety and continuity. This product uses sealed lead-acid batteries and is recommended for optimal performance in a dry, clean, and stable indoor environment.
With users increasingly prioritizing data security and device lifespan, a reliable uninterruptible power supply (UPS) has become essential for computer use. The launch of the GD-UP09/10/11/12 series provides home and office users with a safer, more intelligent power solution, enabling a truly uninterruptible power experience!
Contact us for more product specifications, samples, and pricing!
Model | GD-UP09 | GD-UP010 | GD-UP011 | GD-UP012 |
| INPUT | ||||
| Voltage | 110Vac | 110Vac/120Vac | ||
| Voltage Range | 81-145VAC | 81-134Vac/89-145Vac | ||
| Frequency Range | 50/60 Hz(Auto sensing) | 50Hz+5Hz/60HZ+5Hz | ||
| OUTPUT | ||||
| AC Voltage Regulation (Batt. Mode) | 110Vac±10% | 110vac/120Vac±10% | ||
| Frequency Range (Batt. Mode) | 50Hz±1Hz or 60Hz±1HZ | |||
| Transfer Time | Typical 4-8ms, 13ms max | |||
| Waveform(Batt. Mode) | Simulated Sine Wave | |||
| BATTERY | ||||
| Battery Voltage | 12V | 24V | ||
| Charge Current | 1.0 A | |||
| Battery number | 4 | 4.5AH/7AH/9AH | 7AH/7.5AH/9AH | 9AH |
| PROTECTION | ||||
| Full Protection | short circuit, Overoad , Overcharge and overdischarge protection | |||
| ALARM | ||||
| Battery mode | Sounding every 10 seconds | |||
| Low Battery | Sounding every second | |||
| Overload | Sounding every 0.5 seconds | |||
| Fault | Continuously sounding | |||
| OPERATING ENVIRONMENT | ||||
| Humidity | 0-90 % RH @ 0- 40"℃(non-condensing) | |||
| Noise Level | Less than 40dB | |||
MANAGEMENT | ||||
Communication port | For choice(USB&RJ45) | |||
