GD-UP029
GIDEON
Product Description
Category | Parameters |
|---|---|
Capacity | 650VA/390W, 800VA/480W, 1000VA/600W, 1200VA/720W, 1500VA/900W |
Input Voltage | 110/120 VAC or 220/230/240 VAC |
Input Voltage Range | 81-145 VAC or 145-275 VAC |
Input Frequency | 50/60 Hz (Auto sensing) |
Output Voltage | 110/120 VAC or 220/230/240 VAC |
Voltage Regulation | ±10% (Battery mode) |
Frequency Range | 50/60 Hz ± 1Hz (Battery mode) |
Transfer Time | 4-6ms (Typical) |
Waveform | Simulated sine wave (Battery mode) |
Battery Type & Qty | 12V/7Ah×1, 12V/9Ah×1, 12V/7Ah×2, 12V/9Ah×2 |
Charge Time | 8 hours recover to 90% capacity |
Full Protection | Discharge, Short circuit and Overload protection |
LCD Display | AC mode, Battery mode, Load level, Battery level, Input/Output voltage, Overload, Low battery |
LED Indicators | Line mode (Green), Battery mode (Red), Charging mode (Yellow) |
Audible Alarm | Battery mode (every 4s), Low battery (every 1s), Overload (every 1s), Fault (Continuous) |
Interface | Optional USB/RS232 (Supports Windows XP/Vista/7/8, Linux, Unix, and MAC) |
Humidity | 0-90% RH @ 0-40°C (Non-condensing) |
Noise Level | Less than 40dB |
